Inputs
SIMOCODE pro
7-6 GWA 4NEB 631 6050-22 DS 03
7.3 Operator panel buttons
Description
The operator panel contains buttons 1 to 4 and the
"Test/Reset" button. Correspondingly, the "OP Buttons" function block is
available in SIMOCODE pro with five sockets.
Note
The "OP Buttons" function block can only be used if the operator panel (OP)
is connected and configured in the device configuration!
Note
The operator panel with display does not have a Test/Reset button. The
allocated functions can be carried out via the operator panel menu or via
softkeys. Similarly, the corresponding status signal will then be available at
the "OP Test/Reset Button" socket.
• Operator panel, buttons 1 to 4:
Buttons 1 to 4 are usually used to input control commands for the motor
feeder. Control commands can be, for example:
- Motor ON (ON >), Motor OFF (OFF) for a direct starter
Motor LEFT (ON<), Motor OFF (OFF), Motor RIGHT (ON >) for a reversing
starter.
- Motor SLOW (ON >), Motor FAST (ON >>), Motor OFF (OFF) for a Dahlander
circuit.
However, the buttons 1 to 4 are not rigidly assigned to the above mentioned
control commands, and can be assigned to other functions via different
internal connection of the respective function block socket in
SIMOCODE pro.
• Operator panel, "Test/Reset" button:
The function of the "Test/Reset" button is generally assigned to fixed
functions:
- Reset function for the acknowledgement of pending faults
- Test function for carrying out device tests.
- Operation of the memory module or the addressing plug
Nevertheless, the status of the "Test/Reset" button can be read from the
corresponding socket of the function block and can be assigned to further
functions in SIMOCODE pro.
See also Chapter 10.2 "Test/Reset", Chapter 14.2.2 "Setting the PROFIBUS DP
address". and Chapter 14.3.2 "Securing and saving parameters"..
