Technical data
SIMOCODE pro
D-14 GWA 4NEB 631 6050-22 DS 03
D.5.3 Technical data of the DM-F Local digital module
LED display
DM-F Local
Color Meaning
"READY" OFF System interface disconnected/supply voltage too
low/device defective
Green Device is ready for operation/system interface OK
Flashing
green
Device is ready for operation/system interface is
inactive or faulty
"DEVICE" OFF Supply voltage too low
Green Device is ready for operation
Flashing
green
Self-test
Yellow Configuration mode
Flashing
yellow
Configuration fault
Red Device is defective or interrupted
"OUT" OFF Safety-oriented output inactive
Green Safety-oriented output active
Flashing
green
Feedback circuit not closed when starting condition
has been fulfilled
"IN" OFF Input inactive
Green Input active
Flashing
green
Fault recognized (e.g. cross circuit at the input, sensor
simultaneity not fulfilled)
"GF" OFF No general fault
Red General fault (wiring fault, cross circuit, configuration
fault)
Flashing red General fault (enabling circuit fault, simultaneity not
fulfilled)
"1" OFF Cross-circuit detection OFF
Yellow Cross-circuit detection ON
Flashing
yellow
Configuration mode awaits confirmation
