Data formats and data records
SIMOCODE pro
B-40 GWA 4NEB 631 6050-22 DS 03
B.15 Data record 139 - Marking
The diagnostics
• External fault 1 to 6 (status information, warnings and faults)
• Limit 1 to 4 (status information)
• TM warning T>/tripping T> (status information, warnings and faults)
• Warning/tripping 0/4 - 20 mA mA<> (status information, warnings and
faults)
can be parameterized to have various meanings e.g. fill level >, bearing hot,
etc. To simplify diagnostics, these texts can be saved in the device. These
can be created, read out and displayed, for example, with SIMOCODE ES
The texts do not contain any functions.
Byte.Bit Designation Type Information
0.0 Reserved Byte[4]
4.0 Reserved Byte[6]
10.0 Marking - External fault 1 Byte[10] BU1 BU2
20.0 Marking - External fault 2 Byte[10] BU1 BU2
30.0 Marking - External fault 3 Byte[10] BU1 BU2
40.0 Marking - External fault 4 Byte[10] BU1 BU2
50.0 Marking - External fault 5 Byte[10] BU2
60.0 Marking - External fault 6 Byte[10] BU2
70.0 Reserved Byte[10]
80.0 Reserved Byte[10]
90.0 Marking - Limit 1 Byte[10] BU2
100.0 Marking limit 2 Byte[10] BU2
110.0 Marking limit 3 Byte[10] BU2
120.0 Marking limit 4 Byte[10] BU2
130.0 Marking - TM warning T> Byte[10] BU2
140.0 Marking - TM trip T> Byte[10] BU2
150.0 Marking - Warning 0/4-20 mA> Byte[10] BU2
160.0 Marking - Warning 0/4-20 mA< Byte[10] BU2
170.0 Marking - Trip 0/4-20 mA> Byte[10] BU2
180.0 Marking - Trip 0/4-20 mA< Byte[10] BU2
190.0 Reserved Byte[10]
Table B-16: Data record 139 - Marking
