Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
B-6 GWA 4NEB 631 6050-22 DS 03
B.2 Data record 0/1 - S7 system diagnostics
Byte
Bit
DR0 DR1 Designation Type No error Error Information
0.0 X X Module fault/OK Bit 0 1
0.1 X X Internal fault Bit 0 0
0.2 X X External fault Bit 0 1
0.3 X X Channel fault Bit 0 1
0.4 X X External auxiliary voltage missing Bit 0 0
0.5 X X Front panel plug missing Bit 0 0
0.6 X X Module not parameterized Bit 0 0
0.7 X X Wrong parameters on module Bit 0 0
1.0 X X Module type Bit[4] 3 3
1.4 X X Channel information available Bit 1 1
1.5 X X Application information available Bit 0 0
1.6 X X Substitute diagnostic alarm Bit 0 0
1.7 X X Reserved = 0 Bit 0 0
2.0 X X Application module wrong/
missing
Bit 0 0
2.1 X X Communication fault Bit 0 0
2.2 X X Operating status (0=RUN,
1=STOP)
Bit 0 0
2.3 X X Time monitoring activated Bit 0 0
2.4 X X Supply voltage within module
failed
Bit 0 0
2.5 X X Battery flat (BATTF) Bit 0 0
2.6 X X Total backup power failed Bit 0 0
2.7 X X Reserved = 0 Bit 0 0
3.0 X X
Rack failure (detected by IM/UM) Bit 0 0
3.1 X X Processor failure Bit 0 0
3.2 X X EPROM error Bit 0 0
3.3XXRAM error Bit 0 0
3.4 X X ADC/DAC error Bit 0 0
3.5XXBlown fuse Bit 0 0
3.6 X X PRAL missing Bit 0 0
3.7 X X Reserved = 0 Bit 0 0
4.0 X Channel type Byte 0x7D 0x7D
5.0 X Length of the channel specific
diagnostics
Byte 0x20 0x20
6.0 X Number of channels Byte 0x01 0x01
7.0 X Channel fault vector (one bit per
channel)
Byte 0x00 0x01
8.0 X Reserved Bit 0 0
8.1 X Short circuit Bit 0 0
8.2 X Undervoltage Bit 0 0
8.3 X Overvoltage Bit 0 0
Table B-3: Data record 0/1 - S7 system diagnostics
