Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-19
B.9 Data record 94 - Measured values
1) S7 format:
0/4 mA = 0
20 mA = 27648
2) Representation of the "Thermal motor model":
Value always refers to symm. trip level,
representation in 2% increments in bits 6 - 0 (range 0 to 254%),
bit 7 shows unbalance (fixed level 50%).
3) Representation in Kelvin.
Byte.Bit Designation Type Range Unit Informa-
tion
0.0 Reserved Byte[4]
4.0 Thermal motor model Byte 0 .. 255 See
2
)IM UM
5.0 Phase unbalance Byte 0 .. 100 1 % IM UM
6.0 Cos phi Byte 0 .. 100 1 % UM
7.0 Reserved Byte[5]
12.0 Max. current I_max Word 0 .. 65535 1 % / I
s
IM UM
14.0 Current I
L1
Word 0 .. 65535 1 % / I
s
IM UM
16.0 Current I
L2
Word 0 .. 65535 1 % / I
s
IM UM
18.0 Current I
L3
Word 0 .. 65535 1 % / I
s
IM UM
20.0 Last trip current Word 0 .. 65535 1 % / I
s
IM UM
22.0 Time to trip Word 0 .. 65535 100 ms IM UM
24.0 Cooling down period Word 0 .. 65535 100 ms IM UM
26.0 Voltage U
L1
Word 0 .. 65535 1 V UM
28.0 Voltage U
L2
Word 0 .. 65535 1 V UM
30.0 Voltage U
L3
Word 0 .. 65535 1 V UM
32.0 AM - Output Word 0 .. 32767
See
1)
AM
34.0 AM - Input 1 Word 0 .. 32767 AM
36.0 AM - Input 2 Word 0 .. 32767 AM
38.0 AM - Input 3 Word 0 .. 32767 AM
40.0 TM - Max. temperature Word 0 .. 65535 1 K see
3)
TM
42.0 TM - Temperature 1 Word 0 .. 65535 1 K see
3)
TM
44.0 TM - Temperature 2 Word 0 .. 65535 1 K see
3)
TM
46.0 TM - Temperature 3 Word 0 .. 65535 1 K see
3)
TM
48.0 Reserved Byte[4]
52.0 Active power P D-word 0 .. 0xFFFFFFFF 1 W UM
56.0 Apparent power S D-word 0 .. 0xFFFFFFFF 1 VA UM
60.0 Reserved Byte[4]
Table B-10: Data record 94 - Measured values
