Technical data
SIMOCODE pro
D-12 GWA 4NEB 631 6050-22 DS 03
D.5.2 Technical data of the DM-F Local and DM-F PROFIsafe digital modules
Mounting Snap-on mounting onto 35 mm standard mounting rails or screw
attachment via additional plug-in lugs
Enclosure width 45 mm
System interfaces For connecting to a basic unit, an additional expansion module, a cur-
rent measuring module or a current/voltage measuring module or the
operator panel
Rated control supply
voltage U
s
(according to
DIN EN 61131-2)
AC/DC 110 V - 240 V 50/60 Hz DC 24 V
Operating range •24 V DC: 0.8 up to 1.2 U
s
•110 V - 240 V AC/DC: 0.85 up to 1.1 U
s
Power consumption
DM-F Local:
•DC 24 V: 3 W
•AC/DC 110 V - 240 V: 9.5 VA/4.5 W
DM-F PROFIsafe:
•DC 24 V: 4 W
•AC/DC 110 V - 240 V: 11,0 VA/5.5 W
Safe isolation according
to IEC 60947-1
Between relay enabling circuits/relay outputs
and electronics
Rated insulation
voltage U
i
300 V (at pollution degree 3)
Rated impulse with-
stand voltage U
imp
4kV
Power loss ride-through
time
•DC 24 V: typ. 20 ms at 0,8xU
s
•AC/DC 110 V - 240 V: typ. 20 ms at 0,85xU
s
typ. 200 ms at 230 V
Relay outputs
• Quantity
• Function
2 monostable relay outputs
• Common connection is internally disconnected in a fail-safe manner
by a relay enabling circuit
• Normally open contact, freely assignable to
the control functions
Electrical service life of
relay outputs
0.1 million switching cycles (AC-15, 230 V/3 A)
Relay enabling circuits
•Quantity 2 common switching-type, fail-safe relay enabling circuits
•Function
Fail-safe normally open contacts
• Prescribed short-circuit
protection for relay
enabling circuits/relay
outputs
Fuse links operating class gL/gG 4 A (IEC 60947-5-1), separate for
each relay enabling circuit
