14.3.3 Replacing SIMOCODE pro components
Safety guidelines
Warning
The main power for the feeder and the supply voltage for the basic unit
must be switched off before replacing current measuring modules and
current/voltage measuring modules.
Notice
Please observe the information contained in the operating instructions!
You can find the operating instructions for SIMOCODE pro at:
www.siemens.com/industrial-controls/manuals.
Notice
It is not necessary to detach the wiring from the removable terminals to
replace the components!
Replacing a basic unit
Proceed as follows:
Table 14-9: Replacing a basic unit
Step Description
1 Save the parameters. See Chapter "Securing and saving parameters" on Page
14-9.
2 Switch off the main power for the feeder and the supply voltage for the basic
unit.
3 If necessary, pull the PC cable, the cover or the connecting cable out of the
system interface.
4 Remove the removable terminals. You do not need to detach the wiring.
5 Demount the basic unit.
6 Remove the removable terminals of the new basic unit.
7 Mount the new basic unit.
8 Plug in the wired removable terminals.
9 Plug the connecting cable into the system interface.
10 Switch on the supply voltage for the basic unit.
11 Save the parameters into the basic unit. See Chapter "Securing and saving
parameters" on Page 14-9.
12 Switch on the main power for the feeder.
To Next Page
