Siemens SIMOCODE pro System Manual

Technical data
SIMOCODE pro
D-20 GWA 4NEB 631 6050-22 DS 03
Table D-9: Technical data of the analog module
D.5.6 Technical data of the earth-fault module
Table D-10: Technical data of the earth-fault module
•Short-circuit proof Yes
•Isolation of the output to the
device electronics
No
Connection:
•Tightening torque TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
•Connection cross sections:
- Solid 2x 0.5 mm
2
- 2.5 mm
2
/ 1x 0.5 mm
2
- 4 mm
2
2 x AWG 20 to 14/1 x AWG 20 to 12
- Finely stranded, with end sleeve 2x 0.5 mm
2
- 1.5 mm
2
/ 1x 0.5 mm
2
- 2.5 mm
2
2 x AWG 20 to 16/1 x AWG 20 to 14
Mounting Snap-on mounting onto 35 mm standard mounting rails or
screw attachment via additional plug-in lugs
Display
•Green "READY" LED •Continuous light: "Ready for operation"
•Flashing: "No connection to basic unit"
System interfaces For connecting to a basic unit, an additional expansion
module, a current measuring module or a current/voltage
measuring module or the operator panel
Control circuit
Connectable 3UL22 summation
current transformer with rated
fault currents I
N
•I
Earth fault
< 50 % I
N
•I
Earth fault
> 100 % I
N
0.3 / 0.5 / 1 A
No tripping
Tripping
Response delay (conversion time) 300 ms - 500 ms, additionally delayable
Connection:
•Tightening torque TORQUE: 7 LB.IN - 10.3 LB.IN
0.8 Nm - 1.2 Nm
•Connection cross sections:
- Solid 2x 0.5 mm
2
- 2.5 mm
2
/ 1x 0.5 mm
2
- 4 mm
2
2 x AWG 20 to 14/1 x AWG 20 to 12
- Finely stranded, with end sleeve 2x 0.5 mm
2
- 1.5 mm
2
/ 1x 0.5 mm
2
- 2.5 mm
2
2 x AWG 20 to 16/1 x AWG 20 to 14
