Siemens SIMOCODE pro System Manual

Motor control
SIMOCODE pro
4-32 GWA 4NEB 631 6050-22 DS 03
Settings
You will find detailed information about the settings in:
Chapter 4.2.2 "General settings and definitions".
1)Notice
If a current/voltage measuring module is in use, the transformer must be
connected to the supply cable!
Star-delta starter Description
OFF OFF control command
(connection with arbitrary socket ,
usually with "Enabled control command - OFF" socket)
ON > ON control command
(connection with arbitrary socket ,
usually with "Enabled control command - ON >" socket)
FB ON Auxiliary control input "Feedback ON"
(connection with arbitrary socket ,
usually with "Status - Motor current flowing" socket)
Non-maintained
command mode
•
Deactivated
• Activated
Separate failsafe
function from
control function
• Deactivated
:
Safety-oriented tripping via the DM-F module also affects the
SIMOCODE pro control function, so that additional fault
messages are avoided.
This setting is selected for applications where safety-oriented
tripping directly affects the motor controlled by SIMOCODE pro.
• Activated:
Safety-oriented tripping via the DM-F module does not affect the
SIMOCODE pro control function.
This setting is selected for applications where safety-oriented
tripping does not affect the motor controlled by SIMOCODE pro.
Load type You can choose between:
•
Motor
• Resistive load (see Chapter 4.2.2 "General settings and
definitions")
Feedback time Range 0 - 25.5 seconds (0.5 s
)
Execution time Range 0 - 6553.5 seconds (1 s
)
Change-over pause Range 0 - 655.3 seconds (10 ms increments) (0.00 s
)
Max.
star time
Time-dependent switching from star to delta.
Range 0 - 255 seconds (20 s
)
Current measuring
module installed
1)
The set current and the switching levels for star-delta switching
depend on the mounting place of the current measuring module.
• In delta
: Set current I
s
is reduced to I
n
x 1/√3 (default)
• In supply cable: Set current I
s
= I
n
(rated current of the motor)
Table 4-10: Star-delta starter settings
