Mounting, wiring, interfaces
SIMOCODE pro
13-24 GWA 4NEB 631 6050-22 DS 03
Decoupling module pin assignment
The following table shows the pin assignment of the removable terminals:
Table 13-10: Pin assignment of the removable terminals of the decoupling module
Decoupling module connection example
Fig. 13-16: Decoupling module connection example
Wiring the removable terminals of the expansion modules and the decoupling
module
Connect the system shielding to the PE terminal.
Connection Assignment
Upper terminals
-
Lower terminals
PE System shielding
READY
DCM
3UF7 150–1AA00–0
G/YYMMDD
*
Exx
*
PE
