TB8100 Service Manual Power Amplifier Disassembly and Reassembly 173
© Tait Electronics Limited September 2006
9 Power Amplifier Disassembly and
Reassembly
Caution Touching high-power RF components or circuits
can cause serious burns. We strongly recommend
you do not touch any RF components or tracks in
the PA while it is transmitting.
Caution The TB8100 power amplifier (PA) weighs between
4.8kg (10.6lb) and 5.8kg (12.8lb). Take care when
handling the PA to avoid personal injury.
Important This equipment contains devices which are susceptible to
damage from static charges. Refer to “ESD Precautions”
on page 17 for more information on antistatic procedures
when handling these devices.
This chapter provides information on how to remove and replace the airflow
duct, cover, and front panel.
Note Unless otherwise noted, the instructions and illustrations in this
chapter refer to a 100W UHF (H-band) PA. However, the same
basic procedures and techniques apply to other models of PA.
