TB8100 Service Manual
Reciter Circuit Description
45
© Tait Electronics Limited Sept
ember 2006
Figure 2.8
R
eciter receiver
synthesizer block diag
ram
/R
/N
12.8MHz
Reference
Oscillator
Receiver
VCO
Programmable
Reference Divider
Programmable
VCO Divider
Phase
Detector
Lock Detect
Output
Charge
Pump
f
ref
f
VCOfb
Software
Register
VCO F
eedback
Attenuator
Lock Detect
Circuitry
64/65
Prescaler
F
requency Synthesizer IC
Loop
Filter
VCO
LNA
Buffer
Harmonic
Filter
Fixed Slope
Attenuator
Final
Driver
+20dBm LO
Clock
Data
Chip Select/Latch Enable
Serial Bus
44
46
