Tait TB8100 Service Manual

TB8100 Service Manual Power Management Unit Spare Parts 267
© Tait Electronics Limited September 2006
16 Power Management Unit Spare Parts
This section lists the spare parts available for the TB8100 PMU at the time
this manual was published.
■ Spare modules and circuit board assemblies are listed in Table 16.1.
■ Mechanical parts are listed in Figure 16.1 on page 269 and Figure 16.2
on page 270.
Other items may become available as spares at a later date. Consult your
nearest Tait Dealer or Customer Service Organisation regarding the
availability of specific items.
Table 16.1 Spare modules and circuit boards for the PMU
Description Spares Code
AC module
a
a. Comes complete with PFC control card and HVDC control and microprocessor card.
TBA-SP-WAA0
DC module
b
b. Comes complete with battery control card and DC control card.
12VDC
24VDC
48VDC
TBA-SP-WD10
TBA-SP-WD20
TBA-SP-WD40
standby power supply card 12VDC
24VDC
48VDC
TBA-SP-WDS1
TBA-SP-WDS2
TBA-SP-WDS4
auxiliary power supply board 12VDC
24VDC
48VDC
TBA-SP-WDA1
TBA-SP-WDA2
TBA-SP-WDA4
DC output filter board
c
c. This is the AC converter board as used in a DC PMU. Only the current sense and out-
put filter circuitry is placed on this board.
TBA-SP-WA00
DC microprocessor card
d
d. This is the HVDC control and microprocessor card as used in a DC PMU. Only the
feedback and microprocessor circuitry is placed on this card.
TBA-SP-WAH0
