22 Safety and Servicing Information TB8100 Service Manual
© Tait Electronics Limited September 2006
1.5 Recommended Tools
It is beyond the scope of this manual to list every tool that a service
technician should carry. However, the tools specifically required for
servicing TB8100 equipment are listed in the table below. You can also
obtain the TBA0ST2 tool kit from your nearest Tait Dealer or Customer
Service Organisation. It contains the basic tools needed to install, tune and
service TB8100 equipment.
Important We strongly recommend that you use the TB8100 card
remover (as shown in Figure 15.1 on page 263) for remov-
ing the plug-in cards in the PMU. The card remover is
included in the TBA0ST2 tool kit, and is also available sep-
arately as part number 220-02034-01.
Driver/
Spanner
Size Location / Function
Tor x T8
a
a. Included in the TBA0ST2 tool kit.
M2.5 secure the SMA connector to the reciter and PA front
panel
Torx T10
a
M3 all M3 screws
Torx T20
a
M4 all M4 screws
Pozidriv PZ1 M2 secure the VHF splitter and combiner boards to the PA
heatsink
Pozidriv PZ3 M6 DC input terminals on the PMU
3/32in Allen
key
4-40 UNC secure the RF power transistors to the PA heatsink
5.5mm AF
a
M3 secure the speaker to the control panel chassis
11mm AF secure the BNC/TNC connectors to the reciter rear
panel
5/16in AF
a
secure the RF coaxial cables to the SMA connectors on
the PA and reciter
