TB8100 Service Manual Power Amplifier Spare Parts 195
© Tait Electronics Limited September 2006
11 Power Amplifier Spare Parts
This chapter lists the spare parts available for the TB8100 PA at the time this
manual was published.
■ Spare circuit board assemblies are listed in Table 11.1.
■ Replacement components are listed in Table 11.2 on page 196.
■ Mechanical parts are listed in Figure 11.1 on page 197, Figure 11.2 on
page 198, and Figure 11.3 on page 199.
Other items may become available as spares at a later date. Consult your
nearest Tait Dealer or Customer Service Organisation regarding the
availability of specific items.
Table 11.1 Spare circuit boards for the PA
Description Spares Code
6W board B and C bands
H band
K band
L band
TBA-SP-PD0B1
TBA-SP-PD0H0
TBA-SP-PD0K2
TBA-SP-PD0L0
60W board B and C bands
H band
K band
L band
TBA-SP-PP0B1
TBA-SP-PP0H0
TBA-SP-PP0K2
TBA-SP-PP0L0
control board TBA-SP-PC010
LPF/directional coupler board B band 50W
B band 100W
C band 50W
C band 100W
H band
K band
L band
TBA-SP-PF50B1
TBA-SP-PF100B1
TBA-SP-PF50C0
TBA-SP-PF100C0
TBA-SP-PF0H0
TBA-SP-PF0K2
TBA-SP-PF0L0
splitter board B and C bands
H, K, and L bands
TBA-SP-PSB1
TBA-SP-PSH0
combiner board B and C bands
H, K, and L bands
TBA-SP-PBB1
TBA-SP-PBH0
boost regulator board TBA-SP-PW000
ambient air temperature sensor board TBA-SP-PT10
