Learn more about other trigger types.
Return to the Trigger Setup control window.
Trigger on nth Event (Horizontal Delay Off).
Trigger on nth Event (Horizontal Delay On).
Trigger on nth Event (B-Event Scan).
B event trigger
Set up trigger controls (B event tab)
From the Trig menu, select B Event (Delayed) Trigger Setup.
To use. Use the controls is this window to define the parameters for the B Event trigger.
For information on the controls, click the buttons.
NOTE. On MSO/DPO5000B Series instruments, trigger on B events is available only for Edge trigger.
■
Trigger Summary
■
Trigger Type
■
Settings
■
Source
■
Set to 50%
■
Level
■
Coupling
■
Slope
■
Force Trigger
Trigger setups
DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 459
