Force a trigger
Click this button to force the instrument to trigger and complete the current acquisition, regardless of whether any other trigger
event occurs.
NOTE. This command has no effect if the acquisition system is not running.
Frequency
This timing measurement is a measure of the first cycle in a waveform or gated region. Frequency is the reciprocal of the period;
it is measured in Hertz (Hz) where one Hz is one cycle per second.
Frequency span
The frequency span is the range of frequencies over which the spectral analysis is performed. The maximum span is from DC to
one half of the sample rate (the Nyquist frequency). A smaller frequency span allows a greater range of center-frequency
adjustment. If a larger frequency span is desired, increase the sample rate.
Getting the analysis and connectivity support tools
This instrument offers several tools you can install to support data export for use with data-analysis tools.
These tools ship with the Tektronix instrument that this online help supports. You can find them on the product software DVD that
ships with this instrument. You can find the Readme file on the CD-ROM that you use to install the analysis and connectivity
tools.
For more information:
■
For general information and examples on how each of these tools can help you use your instrument, see the Getting Started
with OpenChoice Solutions Manual with the CD-ROM (020-2513-XX).
■
For online information about the VXIplug&play driver, access the driver online help in from the help system of your software
development environment in which you install the driver. The driver online help describes each function of the driver and
presents these components in a hierarchical outline corresponding to the standard VXIplug&playmodel.
■
For further reference information on TekVISA, see the TekVISA Programming Manual (071-1101-XX).
■
For online information on the TekVISA Excel toolbar, access the online help for the TekVISAExcel Toolbar from the Excel
Help menu once you have installed the toolbar.
Ground terminal
Use this terminal to connect the instrument to the same ground as the unit under test.
Guidelines for working with math waveforms
Use the following guidelines when working with math waveforms:
■
Keep math waveforms simple. If the math expression becomes too complex, try separating the expression into more than
one math waveform and then combining the waveforms (for example, Math1 = Math2 + Math4).
■
Math calculations are not available on digital channels.
■
You cannot use math waveforms with Fast Acquisition mode.
■
Math waveforms cannot be turned on without a math expression.
■
Math waveforms cannot be created from a reference waveform that was saved in Fast Acquisition mode.
■
To avoid syntax errors in a math expression, verify the use of operators, parentheses, operands, and the spelling of
functions before activating the math waveform.
Oscilloscope reference
762 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
