Tektronix DPO7054C Printable Help

To use.
■
Under Recall What, click Waveform.
■
From the Destination drop-down list, select the Ref <1– 4> location that you want to recall the waveform to. The default
folder for reference waveforms is C:\Users\[Username]\Tektronix\TekScope\Waveforms.
■
Use the pop-up keyboard to enter a File name, or click the file name to select it.
TIP. If you do not see the file that you want to recall, verify that the Files of type list shows the correct file format. You may
also need to check other folders if the file was stored in a location other than the C:\Users\[Username]\Tektronix\TekScope
\Waveforms folder.
Behavior. This dialog box opens when you click Recall from the File menu or when you click the Recall button from the
Reference waveform controls. Waveforms are stored in WFM file format, which is an internal format of the instrument. When you
click Recall, the Ref 1-4 waveform is displayed in the graticule.
NOTE. When you recall a reference waveform, a temporary file containing the waveform data is written to C:\Users\[Username]
\Tektronix\TekScope\Waveforms. The file is named TDS_REF n.WFM, where n is the reference waveform number. This file is
deleted when the reference waveform is deleted.
What do you want to do next?
Learn about saving a waveform to a file.
Learn about deleting waveform files.
Delete setups and reference waveforms
From the File menu highlight Delete; then select an entry in the submenu.
Overview. Use this dialog box to delete a saved reference waveform or setup file.
To use.
■
Select the setup or reference waveform you want to delete.
■
To delete all Setups at the same time, select All Setups
■
To delete All Reference Waveforms at one time, select All Refs.
Behavior. Setups or waveforms stored in Windows directories can be deleted by clicking the in the Save or Recall dialog
boxes.
NOTE. You can only delete setups and reference waveforms stored in oscilloscope memory using this command.
What do you want to do next?
Learn about saving instrument setups.
Learn about restoring instrument setups.
Learn about saving a waveform to a file.
File menu
530 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
