1.3 Specifications
1-18
1.3.2 Monitor unit
Table 1.3.4 List of Monitor Unit
Monitor Unit MU-231CR MU-201CR
Monitor size 23.1 inch 20.1 inch
Monitor type Color LCD
Arrangement Desktop or Flush Mounting
Display area 470.4 x 352.8 mm 399.36 x 319.49 mm
Effective monitor
diameter
340 mm 308 mm
Effective display
diameter classification
340 mm 250 mm
Resolution
20 inch: SXGA (1280x1024 pixels)
23 inch: VXGA (1200x1600 pixels)
Indication Monotone/Multi Colors, 32 tones
Input power 100 to 230 VAC or 24 VDC
Table 1.3.5
Range Scale
and Range Ring
Range scale
0.125 0.25 0.5 0.75 1.5 3
4 6
Range ring
0.025 0.05 0.1 0.25 0.25 0.5
1 1
The Number of rings
5 5 5 3 6 6
4 6
Range scale
8 12 16 24 32 48 96
Range ring
2 2 4 4 8 8 16
The Number of rings
4 6 4 6 4 6 6
Note:
The ranges in the meshed frames are not available for IMO/A type. For changing the
Model Type, change the setting of “IMO/A, B, C and W” on [Menu] -> 0 -> 4 -> 7.
Type.
