Furuno FAR-2827 Service Manual

1.3 Specifications
1-19
1.3.3 Current power consumption
Table 1.3.6 Current Consumption
MU-231CR/MU-201CR:
Monitor Unit Input Voltage
RPU-013:
Processor Unit Input Voltage (100 knot)
Model: FAR-
24 VDC 100 - 230 VAC
24 VDC
24/42 rpm*
100 - 115 VAC
24/42 rpm*
220 - 230 VAC
24/42 rpm*
2117 7.6/8.5 A 2.6/3.0 A 1.6/1.7 A
2127
2.3 A
0.7 A
(100 VAC)
8.8/9.7 A 3.0/3.4 A 1.8/1.9 A
2817 7.6/8.5 A 2.6/3.0 A 1.6/1.7 A
2827
3.2 A
0.9 A
(100 VAC)
8.8/9.7 A 3.0/3.4 A 1.8/1.9 A
2117-BB 7.6/8.5 A 2.6/3.0 A 1.6/1.7 A
2127-BB 8.8/9.7 A 3.0/3.4 A 1.8/1.9 A
2137S 0.7 A (100 VAC) 3.0 A 1.5 A
2837W 3.2 A 1.6 A
2837S 3.0 A 1.5 A
2837SW
0.9 A (100 VAC)
3.0 A 1.5 A
2137S-BB 3.0 A 1.5 A
Note: 24/42 rpm: Current by the Antenna revolution
Table 1.3.7 Current Consumption of 30 kW S-band Radar Antenna Motor
Antenna Motor Input Voltage (100 knot)
Model:
FAR-
- 200 VAC 3 Ph. 50 Hz
- 220 VAC 3 Ph. 60 Hz
21/26 rpm
- 380 VAC 3 Ph. 50 Hz
- 440 VAC 3 Ph. 60 Hz
21/26 rpm
220 VAC
3 Ph. 50 Hz
45 rpm: HSC
220 VAC
3 Ph. 60 Hz
45 rpm: HSC
440 VAC
3 Ph. 60 Hz
45 rpm: HSC
2137S 3 A 1.5 A 3.5 A 3.5 A 1.7 A
2837S 3 A 1.5 A 3.5 A 3.5 A 1.7 A
2837SW 3 A 1.5 A
2137S-
BB
3 A 1.5 A 3.5 A 3.5 A 1.7 A
