Furuno FAR-2827 Service Manual

6.5 Replacement of Major Parts
6-41
2. PWR, HV and FIL board
When replacing the PWR board, pay attention to the gearbox type (antenna speed) and
power input type. When replacing the TX-HV board, pay attention to the radar output
power.
Table 6.5.7 Combination of PWR, HV and FIL Board
PWR board FIL board TX HV board
Power
input
AC type DC type AC type DC type 12 kW
25 kW or
more
03P9339A
(ANT: 24 rpm)
100 VAC
03P9339B
(ANT: 42 rpm)
03P9339C
(ANT: 24 rpm)
220 VAC
03P9339D
(ANT: 42 rpm)
03P9341
03P9338C
(ANT: 24 rpm)
24 VDC
03P9338D
(ANT: 42 rpm)
HV9017B
03P9338A
(ANT: 24 rpm)
12 to
24 VDC
03P9338B
(ANT: 42 rpm)
03P9352
HV9017A
Note:
- Changes of the PWR board type can be coped with by the setting of jumper.
See p.4-64 for details.
- Changes of the HV board type can be coped with by the setting of jumper.
See p.4-70 for details.
