Furuno FAR-2827 Service Manual

4.4 Initialize Setting
4-25
4.4.9 TYPE: IMO/A/B/C/W
INITIALIZE -> 4: INSTALLATION -> 7
Specifications differ slightly according to the type setting. See table 4.4.4.
- IMO: IMO compliant - A: Near-IMO specifications
- B: Non-Japanese fishing vessels - C: Japanese fishing vessels
- W: Washington state (USA) ferry
Note:
The W-type is added on the Ver-014 of the SPU program or later. The W-type
(Washington State Ferry type) is a special type with some specific ship function
added to the B type. The W-type has the function for some specific ship (Washington
State Ferry type), which is a function added to the B type.
Table 4.4.4(1/2) Functions for Radar Type (Differences in Main Menus)
Type
Differences in Main Menus
IMO A B C
Menu – 1:MARK – 7:ECHO AREA
(ECHO AREA can be selected from CIRCLE/WIDE/ALL.)
NO NO YES YES
Menu – 2:MARK – 9:EBL CURSOR
(Only when NM is selected for the unit of the range, switching between
REL and TRUE is enabled.)
YES YES NO NO
Menu – 2:MARK – 9: [EBL,VRM, CURSOR SET]
(Selection of the unit of the range from NM/SM/km and kyd. And also,
switching between REL and TRUE.)
NO NO YES YES
Menu – 3:ALARM – 6: [ALARM OUT1], 7, 8, 9 –> 9:ALARM OUT
POLARITY
(Setting of alarm output polarity)
NO NO YES YES
Menu – 4:ARP/AIS – 5: ARP SYMBOL – 2: ARP SYMBOL COLOR -> RED
(Restriction on ARP symbol color)
NO YES YES YES
Menu – 4:ARP/AIS – 6: AIS SYMBOL – 2: AIS SYMBOL COLOR -> RED
(Restriction on AIS symbol color)
NO YES YES YES
Menu – 5: PLOTTER – 2: CHART COLOR
(Setting of CHART COLOR)
NO YES YES YES
Menu – 5: PLOTTER – 5: TGT TRACK INTERVAL NO YES YES YES
Menu – 5: PLOTTER – 6: TGT TRACK COLOR
(Selection of track color of other ship)
NO YES YES YES
Menu – 5: PLOTTER – 8:[DATA ERASE] – 3:TARGET TRACK
(Erasing of track of other ship)
NO YES YES YES
Menu – 5: PLOTTER – 9: DISPLAY – 2:GRID – OFF/ON
(To display grid or not)
YES YES YES NO
Menu – 5: PLOTTER – 9: DISPLAY – 2:GRID – OFF/L/L/GYOKU
(ON/OFF of GYOKU ”Fishing area” display)
NO NO NO YES
Menu – 5: PLOTTER – 9: DISPLAY – 4: TARGET TRACK
(To display of track of other ship or not)
NO YES YES YES
Menu – 5: PLOTTER – 9: DISPLAY – 6: LAND DENSITY
(To display the land density or not)
NO YES YES YES
Menu – 5: PLOTTER – 9: DISPLAY – 7: PLACE NAME
(To display the place name or not)
NO YES YES YES
