3. Main operations for each function
Table 4.4.2 Functions of LAN and SUB
Main function
LAN connection
(Inter switch function)
FAR-2xx7 set
as sub monitor
(SUB function)
PULSE LENGTH Linked
RANGE Linked Enabled
A/C SEA Linked
GAIN Linked
A/C RAIN Linked Enabled
PICTURE Linked Enabled
TX/STBY Linked
ARPA ACQ Linked
TARGET CANCEL Linked
[ARPA]->1: ARPA SELECT Linked
[Menu]->0->6->7->3:ANT SELECT Linked
LOST ACK Linked
ARPA vector Linked
ARPA CPA/TCPA Linked
TUNE MANUAL Linked
TUNE AUTO Linked
[Menu]->0->3->2, 3:BLIND SECTOR Linked
[Menu]->0->4->5: RADAR POSN Linked Enabled
[ARPA]->2: ALL CANCEL Linked
REF POINT Linked
Image processing etc.
・ES ・EAV ・Echo trail ・Wipper
Individual operation Enabled
IR, Auto RAIN Linked
Zoom Individual operation Enabled
Vector time/Vector mode Individual operation
ARPA/AIS plot interval Individual operation
ARPA acquisition and tracking
Receives data from the
other dispaly
Guard zone
Displays data of the other
dispaly
Alarm zone Individual operation Enabled
HDG data
Displays data of the other
dispaly
Displays own data
NAV data other than HDG data Displays own data Displays own data
[Menu]->3: TUNE INITIALIZE Own radar only
PM, SART Own radar only
OFF SET, HD OFF Individual operation Enabled
EBL, VRM Individual operation Enabled
IL Individual operation Enabled
Switch display mode and presentation mode Individual operation Enabled
Mark、BRILL operation
Individual operation Enabled
Note: “Individual operation” mentioned in “LAN connection” column of the above
table refer to operations when INTER SW PRIORITY is set to OFF on the
respective radars. And “Linked” means that the setting on one side radar
makes the same setting on other radars.
