Furuno FAR-2827 Service Manual

4.10 Setting of RGB BUFF Board: 03P9229B
4-57
4.10.3 Setting of the Video Channel in the VDR
Table 4.10.3 Setting of the Video Channel in VDR
Item Setting
Channel # VD 1 VD 1 VD 1 VD 1
Channel ID
FAR-28x7
(Input the model name)
FAR-21x7
(Input the model name)
FR-2105
(Input the model name)
FR2805
(Input the model name)
Source
NO.x RADAR
(Input the radar No.)
NO.x RADAR
(Input the radar No.)
NO.x RADAR
(Input the radar No.)
NO.x RADAR
(Input the radar No.)
Source type 1 1 1 1
Horizontal offset
Note-1
127 167 175 245
Vertical offset 37 37 40 17
Pll multiplier 847 847 847 1375
Horizontal sync
polarity
Note-2
Negative Negative Positive Negative
Phase 192 192 192 48
Horizontal resolution 1280 1280 1280 1066
Vertical resolution 1024 1024 1024 800
VCO range 48 48 48 44
Save image to web Saved as JPEG Saved as JPEG Saved as JPEG Saved as JPEG
Debug level None None None None
Color mask bit
15-bit
(11111000 x 3)
15-bit
(11111000 x 3)
15-bit
(11111000 x 3)
6 - bit
Sample rate 15 Secs Fixed 15 Secs Fixed 15 Secs Fixed 15 Secs Fixed
Interlace type Alternate pixel Alternate pixel Alternate pixel Interlaced
Sync type Separate SYNC Separate SYNC Separate SYNC Separate SYNC
Radar model 1 – FR2115 1 – FR2115 1 – FR2115 0-User defined
Contrast/GAIN Red 128 128 128 100
Contrast/GAIN Green 128 128 128 100
Contrast/GAIN Blue 128 128 128 100
Brilliance/OFFSET
Red
128 128 128 100
Brilliance/OFFSET
Green
128 128 128 100
Brilliance/OFFSET
Blue
128 128 128 100
Note-1: Setting of h
orizontal offset
The setting differs according to the display screen size of S1-#1 and #2 of the SPU board. See
p.4-41.
Note-2: Setting of horizontal sync polarity
The setting of the polarity of synchronizing signal can also be made in the setting of JP-4 and 5
on the RGB BUFF board. If the polarity setting is not correct, discolored ares are appeared
when pictures reproduce on VDR.
