7.3 Processor Unit: RPU-013
7-30
2.
Connector
Table 7.3.1(1/2) Connector on the TB board
TB board (03P9342) Connector No. Overview
J609 (Terminal) IF VIDEO sig.
Input of MIX (Video Sig.,) 60 MHz IF receiving signal from
TR unit
J651 (2P-VH) HV HV input from TX high voltage board (HV-9017)
J652 (10P-VH) PWR For connecting to the PWR board
J653 (Mini-Pin) SPU
MIX: (Video Sig.,) 60 MHz IF receiving signal inputted into the
SPU board (1.5 D co-axial cable)
J654 (80P) SPU For connecting to the SPU board
J601
(male: 9pin D-SUB)
PC
- Program updating port of RS-232C type
- ON/OFF switching of Shuttle Ferry function
J602 (10P-XH) KEY
For connecting control unit (RCU-014) or RCU-015. Not
connectable to RCU-016 because it has no power switch.
J603 (6P-XH) GC-10
Connector to be used when GC-10 is incorporated
(HDG setting is made in [HDG] -> AD-10)
J604 (2P-WAGO) PSU
Used with FAR-2x37S and connected to PSU-007 by antenna
ON/OFF signal and turns on and off the antenna motor power
supply line by relay
J605 (3P-WAGO) HEADING
Heading data input from IEC61162-1 and 2 types. Supports a
range between 4800 bps to 38.4 kbps according to input data
speed and automatically switched (HDG setting is made in
[HDG] -> Serial)
J606 (3P-WAGO) NAVIGATOR
Connector to navigator system of IEC61162-1 and 2 types.
Supports a range between 4800 bps to 38.4 kbps according to
input data speed and automatically switched
J607 (3P-WAGO) LOG
For connecting to log serial signal of IEC61162-1 and 2 types.
Supports a range between 4800 bps to 38.4 kbps according to
input data speed and automatically switched
J608 (WAGO-4P)
AD
CONVERTER
Heading data input in AD format. Set the input interval to 25
msec. (HDG setting is made in [HDG] -> AD-10)
J610 (12P-WAGO) SCANNER Connected to the scanner unit
J611 (5P-WAGO) AIS AIS connection connector of IEC61162-2 type
J612 (12P-WAGO) EXT. ALARM
Four alarm output ports. Contact signal by MOS-FET contact.
Polarity of ALM 4 is opposite to that of other ports.
Sys Fail x1 and EXT ALM Ack should be inputted.
J613 (2P-WAGO) SCANNER Connected to the TR unit by TX HV
J614 (2P-WAGO) CARD I/F +12 VDC power supply output of CARD I/F (CU-200)
J615 (5P-WAGO) OPTION
Power supply output for DVI I/F and RGB Buff boards (+12 V,
+5 V and –12 V)
J616 (8P-NH) MASTER Radar
Connector for Video, HD, B.P and Trig input signals from
master radar
J617 (8P-NH) SUB DISPLAY-1
Connector for Video, HD, B.P and Trigger output signals from
this radar. Video signal is in FULL-LOG.
To Next Page
