Furuno FAR-2827 Service Manual

3.2
Box Menu
Box Menu Box Menu
Box Menu
3-17
[BRILL]
Table3.2.11 BRILL Box Menu
Menu Submenu Description
BRILL 1/2
1 ECHO COLOR YEL/GRN/WHT/COLOR
Allows the setting of echo color.
The “COLOR” setting is not available on IMO and
A type radars.
2 BKGD COLOR
BLK-GRN/BLK-RED/BLU-C
IR/BLU/BRT-BLU
Allows the setting of background color.
3 PANEL DIMMER
4 CHARACTER
5 CURSOR
6 ECHO
7 TRAIL
8 HL
9 RING
Adjusts the respective brilliance
0 NEXT
BRILL 2/2
1 BACK
2 BRG CURSOR
3 EBL
4 VRM
5 INDEX LINE
6 ARP SYMBOL
7 AIS SYMBOL
8 L/L GRID
9 MARK
0 CHART
Adjusts the respective brilliance
The “0. CHART” is not available on the IMO-type
radars.
[BRILL1 MENU (2/2)]
1 BACK
2 BRG CURSOR
3 EBL
4 VRM
5 INDEX LINE
6 ARP SYMBOL
7 AIS SYMBOL
8 L/L GRID
9 MARK
0 CHART*2
[BRILL1 MENU (1/2)]
1 ECHO COLOR**
YEL/GRN/
WHT/COLOR*1
2 BKGD COLOR**
BLK-GRN/
BLK-RED/
BLU-CIR/
BLU/BRT-BLU
3 PANEL DIMMER
4 CHARACTER
5 CURSOR
6 ECHO
7 TRAIL
8 HL
9 RING
0 NEXT
*1: Not available on IMO and A type radar.
*2: Not available on IMO radar.
**: Settings for brilliance sets BRILL2-BRILL4
BRILL2: ECHO COLOR: YEL
BKGD COLOR: BLK-RED
BRILL3: ECHO COLOR: YEL
BKGD COLOR: BLU-CIR
BRILL4: ECHO COLOR: YEL
BKGD COLOR: BLU
