4.8 Add to the Memory Card I/F: CU-200
4-49
How to return the original setting
1. Turn the power off.
2. Set IP0 of DIP switch (S1) to OFF and INIT to ON.
3. Turn the power on and wait until CR2 starts to blink.
4. When CR2 starts to blink, turn the power off and return INIT of S1 to OFF.
5. IP address was changed from 172.031.014.101 to 172.031.014.100.
2．
．．
．Confirmation of IP address
You can check the radar IP address, “Card 1 IP address” and “Card 2 IP address” on
“[MENU] -> 0 -> 7:NETWORK”.
“CARD x IP ADDRESS” appears when CU-200 is recognized.
Table 4.8.2 Assignment of IP address and Drive
CU-200 IP address
Assignment of drive
[MENU]->[6 CARD]->2. DRIVE SELECT
CARD 1 172.031.014.100 A (Left slot) / B (Right slot)
CARD 2 172.031.014.101 C (Left slot) / D (Right slot)
Note
After the IP address of CU-200 connected with the LAN is changed, be sure to
restart the power for other radars and HUB-100 connected with the LAN.
To Next Page
