Furuno FAR-2827 Service Manual

AP1.4
AP1.4 AP1.4
AP1.4 Configuration of the Sentence from
Configuration of the Sentence from Configuration of the Sentence from
Configuration of the Sentence from ECDIS
ECDISECDIS
ECDIS(FEA) to
(FEA) to (FEA) to
(FEA) to ARPA
ARPAARPA
ARPA(FAR.)
(FAR.)(FAR.)
(FAR.)
AP1-27
1.4.14 PAESW - Waypoint List
$PAESW , llll.lll , a , yyyyy.yyy , a , c—c , x , x.x , x.x , a *hh<CR><LF>
1 2 3 4 5 6 7
Contents Data Note
1 latitude, N/S
2 longitude, E/W
3 waypoint identifier ASCII string, 1 to 8 characters
4 number, 1 to 6
5 radius, 0.1 to 2.0
6 channel
- WAYPOINT LIST
ARRAY OF
[LAT, LON, RADIUS,
CHANNEL, NUMBER,
MODE]
7 mode, C/L/E
A= valid
V= no waypoint
L= valid and last waypoint


1.4.15 PAESN - Notebook
$PAESN , A , c—c *hh<CR><LF>
1 2
Contents Data Note
1 status: A= valid NOTEBOOK
(TEXT, VALID)
2 text string, 0 to 71 chars
