Furuno FAR-2827 Service Manual

6.5 Replacement of Major Parts
6-39
3. Control unit: RCU-014, RCU-015, RCU-016
Table 6.5.3 Board Incorporated in Control Unit
Board Type Code Remarks
03P9343 00853636000 RCU-014
CONTROL
03P9344 00853638000 RCU-015, RCU-016
BUZZER 03P9362 00853637000 RCU-014
TRACK BALL TA4726N 00014713900 Common
4. Monitor unit: MU-231CR, MU-201CR
Table 6.5.4 Boards Incorporated in Monitor Unit
Board Type Code Remarks
LCD Panel
FLC59UXC8V-04
(03S9635)
00051554500
For MU-231CR
(LCD I/F, Inverter)
LCD Panel NL128102AC31-02 00015153700
For MU-201CR
(LCD I/F, Inverter)
CCLF
FLCL-23
(03S9687)
00014946700
FAN MOTOR MMS-06C12DS-R02 00012840800
For MU-231CR
LCD
201MU-1
(03S9632)
00014905900
Backlight unit
201LHS2F
(03S9723)
00015030400
Inverter board
201PW21F
(03S9724)
00015030500
For MU-201CR
BSM501FN1 00015036400 For MU-231CR
DVI I/F
SLB-FRN3-A 00015073700 For MU-201CR
FILTER 03P9360 00853652000 For MU-231CR
12 V power supply PKW12-13RE-P
FIL LF-205A 00058841100
MU-231CR/MU-201CR
(Common)
AC type
12 V power supply 03P9359 00014737600
FIL MXB-1206-33 00012676000
MU-231CR/MU-201CR
(Common)
DC type
5. Card Interface unit: CU-200
Table 6.5.5 Boards incorporated in CU-200
Board name Model Code Remarks
NET-100 03P9332 00853621000 Common with RPU-013
CARD CPU 03P9333 00853620000
CARD CON 03P9345 00853622000
