5.1 Overview
5-3
5.1.2 Preparation
1. To check program numbers;
Carry out self-test: [MENU]-9-8-2(SELF TEST).
Program numbers are displayed as below.
Fig. 5.1.2 SELF TEST Screen
- SPU Processor unit (SPU board: MAIN, ARPA, DRAW CPU)
- RFC Transceiver unit (RFC board: RFC CPU)
- KEY Standard control unit: RCU-014
- REMOTE 1 Trackball control unit: RCU-015
- REMOTE 2 Remote control unit: RCU-016
- CARD Card I/F unit: CU-200
Note:
The program for KEY, REMOTE 1, and REMOTE 2 is the same.
<SELF TEST>
SPU
RFC
KEY
REMOTE1
REMOTE2
CARD
PROGRAM No.
0359204-02.xx
0359202-01.xx
0359203-01.xx
*******-**.**
*******-**.**
0359209-01.xx
ROM RAM DIP SW
0000
0000
OKOK
OKOK
OKOK
OKOK
** **
** **
PROCESSOR UNIT MONITOR
RF UNIT MONITOR
-12V
3.3V
5V
12V
SCANNER MOTOR
-12V
3.2
4.8
12.0
0.0
TEMPERATURE
TUNE IND
HV
R.MONITOR
MAG CURRENT
HEATER
12V
-12V
5V
32V
TUNE OUT
TRIGGER FREQ
ANT SPEED
000000 0 0
0
0
28
88
To quit press [F1] key twice
Program numbers are displayed.
