Q & A
8-10
40. The [BRILL] box menu is not displayed. And the brilliance cannot be
adjusted even by turning the BRILL control.
See page.4-41 and 7-73.
Check the setting of S1 of the SPU board. The setting of S1 is set to the “BB”
type.
41. The monitor size and picture size does not match each other.
See page.4-41 and 7-73.
Check the setting of S1 of the SPU board.
42. NMEA data is shared in the LAN connection.
See page.4-51.
The setting to share NMEA data is as follows. However, the HDG data is
excluded from the shared use.
The radar setting on the sending side:
- Select “ON” in [OS POSN] -> 3. SIO DATA LAN OUTPUT
- Select GPS-1 or GPS-2 for the GPS input port in [OS POSN] -> 1. NAV AID
For prevention of a collision, the radar setting on the receiving side is as follows:
- Select “OFF” in [OS POSN] -> 3. SIO DATA LAN OUTPUT
- Select “LAN” in [OS POSN] -> 1.NAV AID
43. The number of mark points
The number of stored points of MARK and LINE is 20,000 and the number of
points of OWN TRACK is 20,000. Separate from these, the ARPA has a storage
area for TARGET TRACK. The number of stored points of ARPA are 15 targets
x 1,000 points.
44. Can marks and lines created on GD-280 and GD-680 be used?
It is possible by converting GD-200/680 data into the GD-3000 format using the
conversion software “GD8891wim”. All data cannot be converted and some marks
may be presented by different shape.
45. What can be saved on a memory card CU-200?
See page.6-45 to 6-47.
Select an item to be written in [Menu] -> 6. The character at the head of a file
name differs according to the selected item. If “MARK” is selected, the file name
is Mxxxxxxx. When the NAV LINE WPT is selected, the file name is Nxxxxxxx.
To Next Page
