[TRAIL]
Table 3.2.12 TRAIL Box Menu
Menu Submenu Description
1 TRAIL MODE REL/TRUE
Allows the setting of the TRAIL MODE. For the
TRUE mode, L/L and Gyro data are required.
2 TRAIL GRAD SINGLE/MULTI
Sets whether to present the trail display in monotone
or gradual shading.
3 NARROW TRAIL OFF/ON
This function is not available on IMO and A-type
radars.
4 TRAIL LEVEL 1/2/3/4
Allows the setting of the echo level for trails.
** OFF -> 1 -> 2-> 3 -> 4: echo level high **
5 TRAIL RESTART OFF/ON
You may clear all target trails and restart the trail
process. Target trails are cleared, and trail process
restarts from time count zero at the current target
trail plot interval.
6 TRAIL COPY OFF/ON
This is a function to allow copying the trail echo
when the range is changed. The effective range is
three times or one third of the previous range. If the
trail is set out of this effective range, the trail is
restarted.
7 OS TRAIL OFF/ON
Turns on and off the own ship trail.
.
[TRAIL MENU]
1 TRAIL MODE
REL/TRUE
2 TRAIL GRAD
SINGLE/MULTI
3 NARROW TRAIL*
OFF/ON
4 TRAIL LEVEL
1/2/3/4
5 TRAIL RESTART
OFF/ON
6 TRAIL COPY
OFF/ON
7
OS TRAIL
OFF/ON
* Not available on IMO and A type radar.
To Next Page
