AP1-26
1.4.11 PAESF - Fix Target Acquire/Cancel
$PAESF , A , x , llll.lll , a , yyyyy.yyy , a *hh<CR><LF>
1 2 3 4
Contents Data Note
1 command type, A/C
A= TARGET ACQUIRE
C= TARGET CANCEL
2 target number, 1 to 8
3 latitude, N/S
- FIX TARGET ACQUIRE
(LAT, LON, NUMBER)
- FIX TARGET CANCEL
(NUMBER)
4 longitude, E/W


1.4.12 PLSPL - Chart Segment
$PLSPL , llll.lll , a , yyyyy.yyy , a , llll.lll , a , yyyyy.yyy , a , a , xxx , a *hh<CR><LF>
1 2 3 4 5 6 7
Contents Data Note
1 start latitude, N/S
2 start longitude., E/W
3 end latitude, N/S
4 end long., E/W
5 linetype
C= continuous
O= dotted
D= dashed
T= dot - dashed
E= erase
6 number
1 -- 998: legal lines
999: erase all
- CHART SEGMENT
START LAT
START LON
END LAT
END LON
LINETYPE
COLOR
NUMBER
7 color
B= blue G= green R= red
C= cyan M= magenta
Y= yellow W= white L= black
1.4.13 PLSPS - Chart Symbol
$PLSPS , llll.lll , a , yyyyy.yyy , a , xxx , c—c , a *hh<CR><LF>
1 2 3 4 5
Contents Data Note
1 latitude, N/S
2 longitude, E/W
3 number
1..998 legal symbols
999 erase all
4 label
ASCII string, 1 to 8 characters
legal ASCII values from hexadecimal 20h to 7Fh
- CHART SYMBOL
LAT
LON
LABE
NUMBER
5 color
B= blue G= green R= red C= cyan
M= magenta Y= yellow W= white L= black
E= erase

