5.1 Overview of Updating
5-1
5.1 Overview
5.1.1 Program file
Programs to be updated are:
- Processor unit: SPU board
MAIN CPU, ARPA CPU, DRAW CPU and FPGA Program
- Transceiver unit: RFC board
RFC CPU
Each program is updated in the same connection and method. The table below shows
program folders and the contents of their files. The sizes of the files are just for
reference.
Table 5.1.1 List of Program Files
Program for Processor Unit:
0359204-02.xx
Program for Antenna Unit:
0359202-01.xx
File Name Size File Name Size
Arparom.hex 174 kB Fr2107rf.bin 105 kB
Drawrom.hex 346 kB Uppg.exe 94 kB
Fpgarom.hex 1,030 kB Uprfc.bat 1 kB
Fr2107r.hex 2,025 kB Uprfc.txt 1 kB
Ldarpa.bin 23 kB
Lddraw.bin 23 kB
Ldmain.bin 23 kB
Ldfpga.bin 29 kB
upmain.bat 1 kB
Uparpa.bat 1 kB
updraw.bat 1 kB
upfpga.bat 1 kB
uppg.exe 94 kB
Note:
1. FPGAROM.HEX, LDFPGA.BIN and UPFPGA.BAT files are added from SPU
program Ver-14 and after. However, Updating FPGA Program restricts that “Ver” of a
SPU board is after “Ver.22.” Refer to the following page for how to recognize the
SPU board Ver.
2. The SPU program corresponding to the C-MAP is 0359223-02.14 and after. The
Fr2107rc.hex file is for the C-MAP file.
