AP1-24
1.4.4 DTM - Datum
$ECDTM , aaa , xx.xxx , a , xx.xxx , a , xxxx.x , aaa *hh<CR><LF>
1 2 3 4 5
Talker ID Data Note
1 local datum
2 latitude offset, N/S
3 longitude offset, E/W
4 altitude offset
EI or EC
5 reference datum e.g.) WGS84


1.4.5 OSD - Own Ship Data
$ECOSD , x.x , A , x.x , a , x.x , a , x.x , x.x , N , x.x , A *hh<CR><LF>
1 2 3 4 5 6 7 8 9 10 11
Talker ID/Contents Data Reference
1 heading, degrees true
2 heading status, A= valid
3 course
4 course reference, B/M/W/R/P
M= manually entered
W= water referenced
B= bottom tracking log
R= RADAR tracking of fixed target
P= position system ground reference
5 speed
6 speed reference, B/M/W/R/P
M= manually entered
W= water referenced
B= bottom tracking log
R= RADAR tracking of fixed target
P= position system ground reference
7 drift course (NOT USED)
8 drift speed (NOT USED)
9 speed units,N= knots
10 heading error
Talker ID: EC
- SPEED
- COURSE
- HEADING
- HEADING
- ERROR
(ANGLE)
- SIMULATION
(VALID)
11 simulation: A = valid


1.4.6 ZDA - UTC Time
$ECZDA , hhmmss.ss , dd , mm , yyyy , hhh , mm *hh<CR><LF>
1 2 3 4
Talker ID/Contents Data Note
1 UTC time
2 UTC date
3 local hours difference
Talker ID: EI or EC
- UTC TIME
- LOCAL TIME DIFFENRENCE
4 local minutes difference
