4.4.8 MODEL
INITIALIZE -> 4: INSTALLATION -> 6
Functions change according to the setting of MODEL.
“A, B and C” in the table below represent parameters. For instance, the models
specified as “A” in the column of the STC curve use the same parameters.
Table 4.4.3 Main Functions Changed According to MODE
Main function
MODEL setting
STC
curve
Transmission
pulse
waveform
control
B.P output
calculation
ANT ON
control
signal form
RFC board
Transmission
repetition
frequency
6 6kW X-band A A A NO A
12
FAR-2x17
FAR-2x17BB
A B A NO A
25UP
FAR-2x27
FAR-2127BB
A C A NO A
25
DOWN
FAR-2817W A D A NO A
50 50kW X-band A E A NO B
30UP
FAR-2137S
FAR-2837S
B F B NO A
30
DOWN
FAR-2837SW B G B YES A
60 60kW S-band B H B NO B
Note:
B.P output calculation
B.P inputted from the antenna is 256 pulse /rev. in the S-band radar and 360 pulse
/rev. in the X-band radar. This is automatically recognized by MODEL setting. The
B.P output at Slave port is 360 pulse /rev. on both S and X band radar.
ANT ON control signal from RFC board
Signals controlling the power line of the antenna motor of FAR-2837SW are ANT
ON signals outputted from the RFC board.
For instance, the ANT ON signals are not outputted when the “30UP” is set on
FAR-2837SW, therefore the antenna is not rotated.
