om 5184516-100 Rev. 5 7-1
CHAPTER 7
TABLE
SECTION 1
INTRODUCTION
1-1Overview
The Intelligent Digital Device (IDD), ILLUSTRATION 7-1, is a multi–faceted image
receptor for general fluoroscopy and rapid serial radiography diagnostic proce-
dures.
The IDD device:
• Supports the fluoroscopic image system and video camera.
• Provides a high line rate grid to improve image quality.
• Provides a source to image distance range for a 32 cm II: 72.2 cm (28.4
inches) to 100.2 cm (37.4 inches) or for a 40 cm II: 73.8 cm (29 inches) to
101.8 cm (40.1 inches).
ILLUSTRATION 7-1
PRECISION 500D TABLE OVERVIEW
POWER ASSIST HANDLE
TOWER
CARRIAGE
TABLE TOP
IMAGING DEVICE
BUCKY
FILM PLANE
IMAGE INTENSIFIER (40 cm)
IMAGING DEVICE
OPERATOR CONTROL
PRECISION 500D
TABLE
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
