om 5184516-100 Rev. 5 12-7
2-7Vertical Cassette Holder (Optional)
The vertical cassette holder is used for cross–table radiography. It can be
attached to the table top along the entire length. To install the holder;
1. Engage it on the edge of the table top.
2. Slide it to the desired position.
3. Secure by means of the two thumb knobs.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
