om 5184516-100 Rev. 5 C-3
SECTION 2
DIGITAL IMAGING SYSTEM TERMS
2-1 Symbols
The following symbols are used on the system hardware.
This symbol indicates the system is rated as Type B Equipment according to IEC
601 regulations. This symbol is located on the rear panel of the electronics cabi-
net.
This symbol indicates a double insulated item according to IEC 601 regulations.
This symbol is located on the system camera head.
This symbol indicates an electrostatic sensitive device. This symbol is located on
several components of the system including the interior of the electronics cabinet.
Be sure to follow proper ESD handling procedures when inspecting, installing, or
servicing any component of the system. You may connect your ground strap to
any point on the cabinet chassis.
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
