GE Precision 500D User Manual

om 5184516-100 Rev. 5 A-2
TABLE A-1
MAXIRAY 100 TUBE UNITS
*With Pressure Switch. **For Hybrid Applications.
2-1 Tube Housing
Finish – mist gray or oyster gray baked enamel.
Shockproof housing constructed of aluminum. Lined with lead to minimize leak-
age radiation.
Oil expansion chamber permits fully rated operation in ambient temperature range
from 32° F to 104°F (0°C to 40°C) and permits storage or shipment at temper-
atures as low as –20°F (–29°C) and altitudes up to 20,000 feet (6,096 meters).
Pressure switch mounted in tube housing inhibits exposure if oil pressure due to
excessive heat reaches a preset limit.
Maximum voltage anode or cathode to ground – 82 kVp.
Amber indicating lamp installed in blower housing identifies selected tube unit
prior to exposure initiation.
New Tube Unit Exchange Tube Unit Focal Spot Color
D1179E(FL) D0579E(FL) 0.6–1.0 Oyster gray
D1279E(FL) D0679E(FL) 0.6–1.0 Mist gray
*D1172E(09) *D0572E(09) 0.6–1.0 Oyster gray
*D1272E(09) *D0672E(09) 0.6–1.0 Mist gray
*D1173E(18) *D0573E(18) 0.6–1.0 Oyster gray
*D1273E(18) *D0673E(18) 0.6–1.0 Mist gray
N/A *D0577E(18) 0.6–1.0 Oyster gray
D1179EG(FL) D0579EG(FL) 0.6g–1.0g Oyster gray
D1279EG(FL) D0679EG(FL) 0.6g–1.0g Mist gray
N/A *D0573EG(18) 0.6g–1.0g Oyster gray
*D1172DH(09) *D0572DH(09) 0.6–1.5 Oyster gray
*D1272DH(09) *D0672DH(09) 0.6–1.5 Mist gray
*D1173DH(18) *D0573DH(18) 0.6–1.5 Oyster gray
*D1273DH(18) *D0673DH(18) 0.6–1.5 Mist gray
N/A *D0577DH(18) 0.6–1.5 Oyster gray
N/A *D0573DF(18) 0.6g–1.5 Oyster gray
*D1279EC(FL) *D0679EC(FL) 0.6–1.0 Mist gray
*D1279F(FL) *D0679F(FL) 0.6–1.25 Mist gray
*D1272F(09) *D0672F(09) 0.6–1.25 Mist gray
*D1173F(09) *D0573F(09) 0.6–1.25 Mist gray
*D1273F(09) *D0673F(09) 0.6–1.25 Mist gray
*D1275F(18) *D0675F(18) 0.6–1.25 Mist gray
*D1175DH(18) *D0575DH(18) 0.6–1.5 Oyster gray
*D1275DH(18) *D0675DH(18) 0.6–1.5 Mist Gray
*D1179DL(FL) *D0579DL(FL) 0.6g–1.5 ** Oyster gray
*D1279DL(FL) *D0679DL(FL) 0.6g–1.5 ** Mist gray
