APPENDIX A
MAXIRAY™ 100 TUBE UNITS
ILLUSTRATION A-1
MAXIRAY 100 TUBE UNITS
SECTION 1
APPLICATION
High–speed, 4–inch (100 mm) diameter rotating–anode tube unit and inserts for
high–energy radiographic procedures.
SECTION 2
FEATURES
• Polyrhenium
TM
target, manufactured by General Electric minimizes surface
distortion and provides increased radiation output.
• Anode heat storage capacity of 260,000 Joules (350,000 heat units).
•Kelvinite
TM
high–thermal emittance oxide coatings on anode and rotor provide
high anode heat dissipation of 925 watts (75,000 heat units per minute) for
improved loading and cooler bearings.
NOTE: Refer to appropriate insert data sheet to obtain the full unit data.
