om 5184516-100 Rev. 5 5-8
ILLUSTRATION 5-7
COLUMN DESCRIPTIONS
SECTION 2
START EXAM
2-1Start Exam Scenario
A patient can be selected from the worklist or an existing patient from the patient
list. In this example, HIS/RIS is available and the patient is registered for a proce-
dure.
Depending on system configuration, the exam room monitor is blanked whenever
the patient list is displayed (for patient privacy). The exception is for rooms with
no control room monitor; in this case the exam room monitor will always display
the patient list.
Select Work List tab.
IMAGES COLUMN
STATUS COLUMN
SERIES COLUMN
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
