om 5184516-100 Rev. 5 11-3
TABLE 11-3
GENERAL CABINET SPECIFICATIONS
NOTE: All specifications do not include measurement instumentation accuracy.
3-2General Input Power Specifications
TABLE 11-4
MODEL DEPENDENT SPECIFICATIONS
Dimensions Generator Cabinet
Height: 1600 mm
Width: 550 mm
Depth: 450 mm
Weight: 150kg
PARAMETER JEDI GENERATOR
Input Voltage 380/400/415/440/460/480VAC three phase and Ground without neutral
Daily Voltage Variations +/– 10% (in this range, the generator shall operate without any derating in accuracy)
Line Impedance Specification IEC Specification
Line Impedance The apparent line impedance guaranteed by the customer should be equal or less
than the values indicated below, according to the voltage value and the commercial
power of the generator.
Voltage range (V) line impedance (Ohms)
3 (phase) 65kW 80 kW
380 0.12 0.09
415 0.14 0.11
440 0.15 0.125
480 0.18 0.15
HV cable type IB EEC: 22mm cable de Lyon (<=150pF/m)
USA: 22mm DSI (<=165pF/m)
EEC: 16mm Claymount (<=165pF/m)
HV cable connector=Federal standard
Ground Wire Same as power cable
Inrush Current 600A
Normal Frequency 50/60Hz
Daily Frequency Variation +/–6%
FOR TRAINING PURPOSES ONLY!
NOTE: Once downloaded, this document is UNCONTROLLED, and therefore may not be the latest revision. Always confirm revision status against a validated source (ie CDL).
