The QAP phantom is used to check:
• Edge Sharpness/Resolution
• Image Resolution Uniformity
• Dynamic Range Level Accuracy
• Signal Contrast
• Contrast to Noise Ratio (CNR)
At the completion of QAP, system image quality status will be reported to the
operator and will display one of the following messages:
• QAP has completed successfully. Image Quality is optimal.
• QAP has failed. Image Quality is not optimal. Call GE Service.
• QAP could not be executed. Please run application again or call GE Ser-
vice.
A successful status indicates that all the image quality parameter values are
within the system specification limits. A failed status indicates that one or more of
the image quality parameter values fall outside the system specification limits. If a
system fails QAP, operator is advised to call GE Service to make the proper sys-
tem adjustments or calibrations to regain optimal system image quality. Periodic
QAP tests are recommended to assure optimal system operation.
2-1 How to perform the Quality Assur-
ance Process
1. Close all clinical applications from the IUI console.
2. Select the Utilities tab located across the top of the screen on the IUI console.
3. Select the Service Button from the right menu of the Utilities screen.
4. Select the Image Quality Button located across the top of the Service screen
of the IUI Console. See ILLUSTRATION B-2.
ILLUSTRATION B-2
IMAGE QUALITY BUTTON
5. Select Image Quality > Quality Control Tools > QAP from the left panel,
shown in ILLUSTRATION B-3.
