5-2 VersaMax® Modules, Power Supplies, and Carriers User's Manual – February 2003 GFK-1504K

IC200CHS011

Barrier-Style Interposing I/O Terminals

The Barrier-Style Interposing I/O Terminals (IC200CHS011) interface a Connector-Style

I/O Carrier to field wiring. The unit has a connector for attaching a cable from the

Connector-Style I/O Carrier and 36 barrier-style terminals.

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Ambient 60C

MADE IN USA

110.5mm

(4.35in)

97.8mm

(3.85in)

105.4mm

(4.15in)

IC200CHS011

I/O INTERPOSING

BARRIER STYLE

Each terminal accommodates one or two solid or stranded wires up to AWG #14 (avg.

2.1mm

cross section. A clear protective hinged door covers the wiring terminals. The

printed wiring card provided with each I/O module can be folded and inserted in this door.

PDFsupply.com
