8-6 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K

IC200MDL330

Output Module, 120VAC 0.5 Amp, Isolated 16 Points

Discrete output module IC200MDL330 provides 16 isolated outputs.

1234567 814

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Temp Code T4A Ambient 60C

CLASS I ZONE 2 GROUP IIC TA4

Ex nA IIC T4 OC

≤

60C

Ex nV T4 Demko No. 98Y. 125014

IC200MDL330

OUTPUT 120VAC

ISO .5A 16PT

12345678

910111213141516

An external 120 VAC power supply must be provided to switch power to the loads.

Intelligent processing for this module is performed by the CPU or NIU. The module

receives 16 bits of discrete output data.

LED Indicators

Individual green LEDs indicate the on/off state of the output points. The output

LEDs are logic-driven and independent of the load conditions.

The green OK LED is on when backplane power is present to the module.
