11-54 VersaMax® Modules, Power Supplies, and Carriers User's Manual – March 2003 GFK-1504K
11
IC200ALG331
Analog Output Module, 16 Bit Voltage/Current, 1500VAC Isolation, 4 Channels
Configurable Parameters
The default parameters of this module can be used in many applications. The module can
be software-configured when it is installed in a VersaMax PLC system, or an I/O Station
controlled by a Network Interface Unit that is version 2.0 or above.
Module
Parameter
Description
Default Choices
Analog
Output Data
Reference
Starting offset for the module’s analog output data.
user selectable
Analog
Output Data
Length
Word length of the module’s analog output data.
4 0–4
Report Faults
Enables or disables Fault Reporting for the entire
Module.
Enabled Enabled,
Disabled
%AQ Default
/Hold Last
State
Specifies whether the module will go to the
specified channel defaults (see below) or hold their
last states if power or communications are lost.
Default Default /Hold
Current /
Voltage
Specifies whether the channel will be a voltage or
current output.
If the Channel type is Current, the range is 4 to
20mA.
If Channel type is Voltage, the range is –10 to
+10V.
I (Current) I (Current),
V (Voltage)
Channel
Active
Specifies if the channel should output data
received from the CPU or NIU. If a channel is
“inactive” space is still allocated for it.
Active Inactive (off), Active (on)
Span Low
Actual current (in microAmps) or voltage (in
milliVolts) to be scaled to low engineering units
value.
4000
µ
A 0 to 25,000
µ
A
–10,000 to +10,000mV
Span High
Actual current in microAmps or voltage in millivolts
to be scaled to the high engineering units value.
20000
µ
A 0 to 25,000
µ
A
–10,000 to +10,000mV
Engineering
Low
The engineering units value that is considered
equivalent to the low span (actual) value.
4000 0 to 25,000
µ
A
–10,000 to +10,000mV
Engineering
High
The engineering units value that is considered
equivalent to the high span (actual) value.
20000 0 to 25,000
µ
A
–10,000 to +10,000mV
Default
The value to be output by the firmware when the
module is in a default condition and the Output
Default Control is set to Default.
0
µ
A -32768 to +32767
