GFK-1504K Chapter 4 Carriers 4-17

IC200CHS025

Compact Spring-Style I/O Carrier

The Compact Spring-Style I/O Carrier (IC200CHS025) has 36 IEC box-style terminals. It

provides mounting, backplane communications, and field wiring for one I/O module.

66.8mm

(

2.63in

)

163.5mm

(6.45in)

IND CONT EQ FOR HAZ LOC

CLASS I DIV 2 GROUPS ABCD

Temp Cpde T4 Ambient 60C

CLASS 1 ZONE 2 GROUP IIC

Ex nA IIC 0C <To<60C

Ex nV II Demko No. 98Y.125014

IC200CHS025

COMPACT I/O CARRIER

SPRING STYLE

The I/O module mounts vertically (perpendicular to the DIN rail) on this carrier.
