GFK-1504K 10-1
Analog Input Modules
This chapter describes analog input modules.
IC200ALG230 Analog Input Module, 12 Bit Voltage/Current 4 Channels
IC200ALG240 Analog Input Module, 16 Bit Voltage/Current,
1500VAC Isolation, 8 Channels
IC200ALG260 Analog Input Module, 12 Bit Voltage/Current 8 Channels
IC200ALG261 Analog Input Module, 15 Bit Differential Voltage
8 Channels
IC200ALG262 Analog Input Module, 16 Bit Differential Current
8 Channels
IC200ALG263 Analog Input Module, 15 Bit Voltage 15 Channels
IC200ALG264 Analog Input Module, 15 Bit Current 15 Channels
