GFK-1504K Chapter 1 Introduction 1-19
1
VersaMax General Product Specifications
VersaMax products should be installed and used in conformance with product-specific
guidelines as well as the following specifications:
Environmental
Vibration IEC68-2-6 1G @57-150Hz, 0.012in p--p @10-57Hz
Shock IEC68-2-27 15G, 11ms
0 deg C to +60 deg C ambientOperating Temp.
-40 deg C to +60 deg C ambient for I/O carriers,
interposing I/O terminals, and auxiliary I/O terminals
Storage Temp. -40 deg C to +85 deg C
Humidity 5% to 95%, noncondensing
Enclosure Protection IEC529 Steel cabinet per IP54:
protection from dust & splashing water
EMC Emission
Radiated, Conducted CISPR 11/EN 55011 Industrial Scientific & Medical Equipment
(Group 1, Class A)
CISPR 22/EN 55022 Information Technology Equipment (Class A)
FCC 47 CFR 15 referred to as FCC part 15,
Radio Devices (Class A)
EMC Immunity
Electrostatic Discharge EN 61000-4-2 8KV Air, 4KV Contact
RF Susceptibility EN 61000-4-3 10V
rms
/m, 80Mhz to 1000Mhz, 80% AM
ENV 50140/ENV 50204 10V
rms
/m, 900MHz +/-5MHZ
100%AM with 200Hz square wave
Fast Transient Burst EN 61000-4-4 2KV: power supplies, 1KV: I/O, communication
Surge Withstand ANSI/IEEE C37.90a Damped Oscillatory Wave: 2.5KV:
power supplies, I/O [12V-240V]
IEC255-4 Damped Oscillatory Wave: Class II,
power supplies, I/O [12V-240V]
EN 61000-4-5 2 kV cm(P/S); 1 kV cm (I/O and communication
modules)
Conducted RF EN 61000-4-6 10V
rms
, 0.15 to 80Mhz, 80%AM
Isolation
Dielectric Withstand UL508, UL840, IEC664 1.5KV for modules rated from 51V to 250V
Power Supply
Input Dips, Variations EN 61000-4-11 During Operation: Dips to 30% and 100%,
Variation for AC +/-10%,
Variation for DC +/-20%
